This lab introduces WebAssembly, an assembly language meant for the web. In addition to getting familiar with WebAssembly, students will be visiting and further developing topics they have seen throughout CMPUT 229 such as parsing the binary representation of instructions, managing a data structure in memory, and combining multiple non-trivial tasks into a larger project.
Most of the applications found in the Web are implemented in Javascript. Javascript is widely available and has become a de-facto standard for web applications, and has more recently been used as a target for compilation from other languages. Thus, while many developers may write web applications in a language other than Javascript, the applications have to be compiled to one of the limited options for executable code on a browser (asm.js, PNaCl, etc.) or the code may have to be executed on the browser using a plugin (for example, a Java plugin). WebAssembly (WASM) was designed as an alternative to these previous attempts to develop a common representation of code for the Web. WASM is primarily intended to be a compilation target for other languages (C, C++, etc.) and arose not to replace Javascript but to complement it by offering a more suitable compilation target for other languages. WebAssembly is supported by almost all the major browsers and mobile browsers.
The main task in this assignment is to translate the binary representation of
a RISC-V assembly program into the binary representation of a WebAssembly program.
The solution will parse each instruction in the RISC-V program and map it to a provided
appropriate set of WebAssembly instruction(s). Some special consideration must be given
to branch instructions, the immediate values in any I-type or shift RISC-V instruction,
and using the zero register.
There are many differences between WASM and the RISC-V instruction set. In the RISC-V instruction set, every instruction is 4 bytes long. This simplifies parsing the binary representation of a RISC-V program as the parser can walk a pointer through the representation, incrementing by four after parsing each instruction. However, WASM does not have this guarantee as it can have variable-length instructions. WASM is a bytecode, which means that every instruction has an opcode that is one byte long. Thus, each instruction is at least one byte long. An instruction in WASM is composed of its opcode and its immediates, if present. Immediates may consist of other instructions. As a result, there are no guarantees on the maximum size of a WASM instruction. It is useful to think of WASM 'instructions' as expressions. An expression may be arbitrarily long because it may contain expressions within itself. WASM expressions appear at the bytecode level in postfix notation. Therefore, the bytes representing the operator always come after the bytes representing the operands.
Another way that WASM differs from RISC-V is in the encoding used for literal values. When an application is transferred over the internet, the size of the file must be taken into consideration. WASM was designed to minimize the number of bytes necessary to represent the program. All of the literal values in the program are encoded in LEB128 format, discussed in the LEB128 Literal Format section below. In LEB128, a 32-bit constant may occupy from 1 to 4 bytes. This representation is important when generating WASM instructions and returning the number of bytes generated by the translation program.
While instructions are binary at the lowest level, it is convenient to also represent them in a text format so that human eyes may read the code. The textual representation format of WASM is called WAST and uses S-expressions. This representation is fairly different from the text representation of RISC-V (more can be read on S-expressions here). In this lab, WebAssembly is presented both in text and binary format. However, the solution for this lab must generate the binary representation. Online examples can be found where the WAST S-expressions are presented in either postfix or prefix notation. For example, this prefix ordered expression:
(i32.add (get_local $0) (get_local $1))
Is equivalent to this postfix ordered expression:
(get_local $0) (get_local $1) (i32.add)
Although the textual representation of WebAssembly may be presented in either prefix or postfix notation, the bytecode in a WASM module must be in postfix order. Consider the following postfix ordered S-expression:
(i32.const 1)(set_local $0)
In the bytecode representation of this instruction, each component needs to be translated to a corresponding sequence of bytes. The WASM bytecode corresponding to this statement would exist in a WASM module as such:
The bytecode for i32.const is 0x41,
the bytecode for the 1 integer literal happens to
also be 0x01, and the bytecode for
set_local is 0x21. Finally, the
variable $0 is translated to 0x00, see
Variables for the specifics on how a
submission is expected to handle translating variables.
In RISC-V the textual assembly representation of a RISC-V instruction and its binary representation contain the same information. The textual assembly is easier for the programmer to read and write while the binary representation can be interpreted by the CPU. In WebAssembly, WAST is for programmers and the bytecode representation is for interpreters. The main distinction between the binary representation of a RISC-V instruction and the bytecode representation of a WebAssembly instruction is that WASM makes each part of the instruction a discreet number of bytes while RISC-V compresses every part of the instruction into only 4 bytes.
A WebAssembly program contained within a file is called a module. Each module contains
sections and each section has a header that contains some information
about that section. All sections in a module are optional. Each section's header contains
fields but a header only contains fields that are necessary for a particular
module. A valuable aspect of a WASM module is that it is very small. The smallest possible
valid WASM module is eight bytes: 0x00, 0x61, 0x73, 0x6d, 0x01, 0x00, 0x00, 0x00.
The first four bytes specify that this is a WASM module and the next four bytes specify the WASM
version number. Currently, WASM minimum viable product (MVP) development is settled on version
1. In this assignment, these bytes are provided by the common.s file. The following
sections that are required to run the code produced by the solution are also included in the common.s file:
More information about the layout of a WASM module can be found
here.
A solution to this lab should not include section headers in the WASM binary
representation.
The solution should only translate the RISC-V code, the rest will be handled in
common.s to produce the final WASM module.
The translation from RISC-V to WASM must preserve program semantics. To enable automated marking this assigment defines a clear mapping from categories of RISC-V instructions to WAST expressions. The mapping between RISC-V instructions and WAST expressions that is expected in the generated WASM code is shown below:
| RISC-V Instruction | WAST Expression Format (Prefix) | WAST Expression Format (Postfix) | |
|---|---|---|---|
| Instructions Containing Immediates: | operator var0, var1, immediate |
(set_local var0 (operator (get_local var1) (i32.const immediate*))) |
(get_local var1) (i32.const immediate*) (operator) (set_local var0) |
| Instructions Containing Variables: | operator var0, var1, var2 |
(set_local var0 (operator (get_local var1) (get_local var2))) |
(get_local var1) (get_local var2) (operator) (set_local var0) |
| Control Flow Operators Format: | |||
| Forward Branches: |
|
|
|
| Backward Branches: |
|
|
|
While the translated code is shown here, branch instructions are discussed in further
detail under Branches. Furthermore, WASM requires
structured control flow
whereas RISC-V allows unstructured control flow. A program that has unstructured control flow
can be much more difficult to analyze, by both compilers and humans, than a program with
structured control flow. The structured control flow requirement in WASM
implies that no branch can branch into the body of a (different) loop or
block.
Loops and blocks may be nested. The lab solution is expected to
handle nested loops and nested blocks.
All RISC-V programs provided as input in this lab will have structured control flow. Any test case created for this lab should also have structured control flow. An intuitive way of thinking is to avoid inserting a branch in the middle of a loop that specifies a target that is in the middle of another loop. See the class presentation slides in the Resources section for examples of valid/invalid test cases.
The order the variables matters in the translation.
For example, given the instruction:
add rd, rs1, rs2
the following two translations preserve the semantics of the instruction:
(get_local rs1) (get_local rs2) (i32.add) (set_local
rd)
(get_local rs2) (get_local rs1) (i32.add) (set_local rd)
However the WASM modules produced are different.
To allow for automated grading, the lab solution must produce
the first translation shown above. The general rule for variable
order is that the translation must
follow the variable order in the postfix section of the above table.
To adhere to the structured control flow of a WASM module some bytes must be placed into the WASM binary representation when the branch targets are encountered in the RISC-V program representation. This means that the solution needs to calculate the RISC-V branch targets. The address of a branch target is the address of the instruction that is executed immediately after the branch when the branch condition is true --- the branch is taken. Once they are calculated, these bytes can then be inserted appropriately as the translator scans the instructions of the program. The translator must also identify the direction of the branch: forward or backward branches.
Forward Branches
For this
assignment, a branch instruction whose target is ahead of the
branch instruction in the program is a forward branch. In
WASM there are no labels to mark the target of
branches. Instead, WASM code is structured with blocks. A block
has the following format: (block .. WASM instructions
.. end). A br_if instruction that appears
inside a block is a conditional break that transfers the
execution to the end of the block. A RISC-V forward
branch is translated as the beginning of a block whose first
instruction computes the branch condition. The second
instruction in this block is a
br_if instruction that is the conditional break that
transfers execution to the end of the block if the condition is
true. The syntax for the translation of a forward branch is as
follows:
(block
(comparison_operator (var0) (var1))
br_if 0
...
Where comparison_operator is a WASM operator that
computes the comparison needed for the type of branch that is
being translated. For instance, the translation of a beq requires
i32.eq operator. The i32.ge_s WASM
operator can be used to translate RISC-V
bge. Bytecode translations are specified in the WASM Instructions section. The
0 after the br_if specifies the break
depth. In a WASM program br_if can break out of multiple
blocks. The solution to this lab does not
implement this feature. For the solution, break depth is always
0. Here is an example of a branch instruction and its
translation:
| RISC-V Code | WAST Translation |
|---|---|
|
|
The use of (get_local 22), (get_local 23) to translate registers t0, t1
is specified in the section WASM Variables.
Backward Branches
In general, to determine if a branch is forward or
backward a flow analysis that computes a dominance relation is
needed. These concepts are thought in advanced compiler courses.
Therefore, for this
assignment, a branch instruction whose target appears
before the branch instruction in the code is classified as a backward
branch. The translating of br_if and the comparison operator is
identical to forward branches. The main difference is that
instead of inserting a (block ... end) control
structure, the translator inserts a (loop ... end) control
structure. The byte code for loop must appear right
before the target instruction and the end byte
code appears after the condition and br_if. For example:
| RISC-V Code | WAST Translation |
|---|---|
|
|
If an instruction I is both the target of a
forward branch and the target of a backward branch, the translated
WASM bytecode has the end of the forward branch
block, followed by the loop bytecode, followed by
I. This translation expresses the semantics of the
RISC-V program in the structured control flow of WASM.
Behavior of the br_if Instruction
A potential snag when reasoning about how branches work in WASM is
that the br_if instruction behaves differently in a
(block ... end) structure versus a (loop ... end).
The main difference being that in a block, the br_if acts
like a break; statement in C++, while in a loop it acts
like a continue; statement. That is, when the branch condition is
true, br_if branches to the end of a block,
while in a loop it branches to the beginning, or the instruction
right in front of the (loop bytecode.
Calculating Targets
The calculation of the offset of a branch instruction or of the
target of a jump instruction requires the value contained in the
PC. During program execution, the PC contains the memory address of the next instruction
to execute. In this lab, the representation of the program is located in the user data segment of memory.
The value of the address used to load the binary representation of an instruction into a
register is the value of the PC for that instruction.
In RISC-V a branch instruction specifies the distance between the branch instruction and its target as an immediate value. To compute branch targets, the combination of the value of the PC and the value of the immediate must be used. The following algorithm is recommended to compute branch targets:
PC value (the address of the branch instruction).
Self-branches
An unintuitive consequence of how branch instructions are being translated in this assignment is that
there is no clear/unambiguous way to translate branch instructions that have themself as their target.
Thus, no test cases will ever have a self-branching instruction and students do not need to handle this
situation in their solution. For example, the following code is
not allowed in a test case:
self: beq t0, t1, self
The branch targets need to be calculated beforehand
to insert loop and end bytecodes
where appropriate. One solution is to precompute all of the
branch target addresses and store them somewhere, then for each
instruction to be translated, check if it is the target of a
forward and/or backward branch. This lab requires the
implementation of some table(s) of branch target counts. This(These)
table(s) will, for every instruction in the given RISC-V
program, store two counters indicating: how many forward branches and how many
backward branches target that particular instruction. While
translating the RISC-V program, the solution must access these table(s),
retrieve the counters, and insert the appropriate number of
end or loop bytecodes for every
instruction.
This lab specifies an interface, constituted of three functions, to access the table(s):
generateTargetTable: calculates the appropriate counts
for each branch target in the program; readTargetCount: retrieves the value of the
count for a given instruction from the table, for use when translating instructions; incrTargetCount: increments the count for a
specific target address, helper function for generateTargetTable; The following guarantees for the RISC-V programs to be translated simplify the solution for this lab:
.data section. The implementation
may create two separate tables, one for forward and another for
backward branch target counts, or it may create a single table
with space to store the counters for forward and backward
branches. A possible implementation for the described table(s)
is to have an array of counts indexed by the position of the
instruction in the program. For example, the 10th instruction
will be associated with the 10th count in the table, and so on.
Unlike RISC-V, WebAssembly is a typed language. Functions, values, and blocks have types.
This lab works only with the 32-bit integer
value type, denoted by the notation i32.
A WASM module has a function section that contains all of the function declarations and specifies the variables used in the function. However, this lab is only translating the RISC-V code to a WASM code section and is not concerned with the function section. Therefore, the solution can assume that there is a one-to-one mapping between the registers used in the RISC-V program and the variables declared in the WASM function.
| RISC-V Register | WASM Variable | RISC-V Register | WASM Variable |
a0 (x10) | 0 | s8 (x24) | 14 |
a1 (x11) | 1 | s9 (x25) | 15 |
a2 (x12) | 2 | s10 (x26) | 16 |
a3 (x13) | 3 | s11 (x27) | 17 |
a4 (x14) | 4 | t3 (x28) | 18 |
a5 (x15) | 5 | t4 (x29) | 19 |
a6 (x16) | 6 | t5 (x30) | 20 |
a7 (x17) | 7 | t6 (x31) | 21 |
s2 (x18) | 8 | t0 (x5) | 22 |
s3 (x19) | 9 | t1 (x6) | 23 |
s4 (x20) | 10 | t2 (x7) | 24 |
s5 (x21) | 11 | s0 (x8) | 25 |
s6 (x22) | 12 | s1 (x9) | 26 |
s7 (x23) | 13 | zero (x0) | i32.const 0 |
By default, the arguments declared in the WASM module are
placed into the first n local variables, corresponding to
n arguments. Thus, in this lab, registers
x10-x17 are mapped to variables
0-7. In general, the lab variable mapping is not
required by a WASM module, but it is a requirement for this
assignment to allow automated marking.
The common.s file declares four arguments for each module to provide enough bytes
for the module to be runnable. Any unused argument will contain 0 because all variables are
initialized to 0 in WASM. In general, a WASM module can have an arbitrary number of arguments.
In this assignment, modules are declared to have only four arguments.
WASM does not have a hardwired zero variable. Therefore any
use of the register zero (x0) must be changed to a constant value
of zero (i32.const 0) with corresponding bytes
"0x41 0x00". For example, the following table shows one such translation.
| RISC-V Instruction | WAST | WASM Byte Codes |
or s1 s2 zero |
(((get_local 8) (i32.const 0) i32.or) set_local 26) |
0x20 0x08 0x41 0x00 0x72 0x21 0x1a |
In RISC-V it is possible to find literal constants represented
in various bit fields in instructions. For example, in an
addi instruction, the literal immediate value is
specified in the highest 12 bits of the instruction. The 32-bit
integer value corresponding to an immediate value in RISC-V is
obtained by sign extending (or zero extending depending on the
instruction) the immediate field.
WASM modules specify literals in LEB128 format. This format aims to represent numbers using a minimal number of bytes. An immediate value in LEB128 can take up anywhere from a single byte to as many as needed, depending on its value. LEB128 uses little-endian byte order.
The binary representation of a number is converted to LEB128 with the following steps:
*Note that this should include the sign-bit - that is, the zero following the leading 1-bit if it is positive, or the 1
following the leading 0-bit if it is negative. For example, 64 would need 8 bits: 01000000 and thus
be sign-extended to 14 bits total, or 2 groups of 7.
In the LEB128 format, the most-significant bit on every byte serves to indicate if the following bytes
should be interpreted as a part of the literal. In the same way that the null-terminator
is a sentinel marking the end of a string, the MSB that is 0 is a sentinel marking the
end of the number. Below is an example conversion for the decimal value 345566. There
are more examples in the class presentation in the
Resources section.
To convert 345566 from decimal to LEB128, first convert it to binary:
345566 => 1010100010111011110
Now, break it into groups of 7 bits:
1010100010111011110 => 0010101 0001011 1011110 (Padding with zeros to next multiple of 7).
Add sentinel bits:
0010101 0001011 1011110 => 00010101 10001011 11011110 => 0x15 0x8b 0xde
The encoded number is 0x15 0x8b 0xde. WebAssembly uses little-endian byte order, therefore this number appears as
0xde 0x8b 0x15 in the WASM representation.
The issue of producing the minimal number of bytes becomes more of a concern when working
with negative numbers. For example, consider the number -34. The binary representation
of -34 in a signed 12-bit immediate is 111111011110. If we just directly sign-extend
this to the next multiple of 7 bits we get 1111111 1011110, and we see that the second grouping of
1111111 is extraneous.
Lets do this for the value -12, coming from a 12-bit immediate. First, convert it to binary:
-12 => 111111110100
Clipping it to the first 1 past the most significant 0 bit:
111111110100 => 10100
Sign-extending to the next multiple of 7 bits:
10100 => 1110100
And continue as before.
A browser tool can be used to test/check LEB128 encodings, linked in the Testing section.
Some examples of what the expected output of the encodeLEB128 function is:
| Decimal value of the 12-bit immediate | Argument passed in to a0 | Expected output in a0 |
| 388 | 0x0000 0184 | 0x0000 0384 |
| -64 | 0x0000 0fc0 | 0x0000 0040 |
| 64* | 0x0000 0040 | 0x0000 00c0 |
| 2047 | 0x0000 07ff | 0x0000 0fff |
| 0 | 0x0000 0000 | 0x0000 0000 |
| -2048 | 0x0000 0800 | 0x0000 7080 |
| -1 | 0x0000 0fff | 0x0000 007f |
| 1 | 0x0000 0001 | 0x0000 0001 |
0xc0 is still a part of the encoding for this example,
be careful to write 0xc0 0x00 to the WASM module in this case.
The WASM instruction set has a wide variety of instructions. This assignment only uses the small subset listed below with opcodes in hexadecimal representation.
| Instruction | Opcode | Immediates | Description |
| block | 0x02 | sig : block_type | begin a sequence of expressions, yielding 0 or 1 return values |
| loop | 0x03 | sig : block_type | begin a block which can also form control flow loops |
| end | 0x0b | n/a | end a code section, block, loop, or if |
| br_if | 0x0d | relative_depth : varuint32 | conditional break that targets an outer nested block |
| return | 0x0f | n/a | return zero or one value from this function |
| get_local | 0x20 | local_index : varuint32 | read a local variable or parameter |
| set_local | 0x21 | local_index: varuint32 | write a local variable or parameter |
| i32.add | 0x6a | n/a | sign-agnostic addition |
| i32.sub | 0x6b | n/a | sign-agnostic subtraction |
| i32.and | 0x71 | n/a | sign-agnostic bitwise and |
| i32.or | 0x72 | n/a | sign-agnostic bitwise inclusive or |
| i32.shl | 0x74 | n/a | sign-agnostic shift left |
| i32.shr_s | 0x75 | n/a | sign-replicating (arithmetic) shift right |
| i32.shr_u | 0x76 | n/a | zero-replicating (logical) shift right |
| void | 0x40 | n/a | signature type void, see below |
| i32.const | 0x41 | value : varint32 | a constant value interpreted as i32 |
| i32.eq | 0x46 | n/a | sign-agnostic compare equal |
| i32.ge_s | 0x4e | n/a | signed greater than or equal |
The sig immediate specified above for the control-flow instructions indicates a signature that describes the expected stack operations of this block. Blocks are similar to functions in that they interact with a value stack. The expected return type must be specified. If a block or function has no return value the expected return type must still be specified, similar to a void function declaration in C. For this assignment the signature used for all blocks and loops should be void.
The following are all of the RISC-V instructions that must be handled by this binary translator.
In the encoding, s specifies a source register, t a target register,
d a destination register, i an immediate value.
| Instruction | Encoding | Type |
ANDI d, s, imm |
iiii iiii iiii ssss s111 dddd d001 0011 |
I |
AND d, s, t |
0000 000t tttt ssss s111 dddd d011 0011 |
R |
ORI d, s, imm |
iiii iiii iiii ssss s110 dddd d001 0011 |
I |
OR d, s, t |
0000 000t tttt ssss s110 dddd d011 0011 |
R |
ADDI d, s, imm |
iiii iiii iiii ssss s000 dddd d001 0011 |
I |
ADD d, s, t |
0000 000t tttt ssss s000 dddd d011 0011 |
R |
SUB d, s, t |
0100 000t tttt ssss s000 dddd d011 0011 |
R |
SRAI d, s, imm |
0100 000i iiii ssss s101 dddd d001 0011 |
I |
SRLI d, s, imm |
0000 000i iiii ssss s101 dddd d001 0011 |
I |
SLLI d, s, imm |
0000 000i iiii ssss s001 dddd d001 0011 |
I |
SRL d, s, t |
0000 000t tttt ssss s101 dddd d011 0011 |
R |
SLL d, s, t |
0000 000t tttt ssss s001 dddd d011 0011 |
R |
BEQ s, t, offset |
imm[12|10:5]t tttt ssss s000 imm[4:1|11]110 0011 |
SB |
BGE s, t, offset |
imm[12|10:5]t tttt ssss s101 imm[4:1|11]110 0011 |
SB |
Remember to be careful when translating srai. The immediate isn't the full 12 bits as the other I-Type instructions and the extra 1 will give incorrect immediates otherwise.
At the time that this lab was written, there was no support for a WASM module to return
multiple values. The organization of a module requires the number of return values for a function
to be specified earlier than the code section of the module. The module bytecode provided in the
common.s specifies a single return value. Thus, the WASM code that the solution
generates must always return a value. If the RISC-V code did not specify a return value, the
translated WASM function will return 0. The designated return value variable for this lab is
0 (a0). It is fine to return this variable even if it was not assigned; all local
variables in WASM are initialized to 0.
The return instruction must be in the following format: (return (get_local 0))
This should be in postfix notation as the rest of the instructions, so it should be written to
the WASM representation as (get_local 0)(return).
This return instruction is to be used as the second last
instruction in the module.
The solution for this lab must write the return
instruction followed by the end opcode at the end
of the translated program before returning from
RISCVtoWASM.
The goal of this assignment is to translate the binary representation
of a RISC-V assembly program into the binary representation of a WebAssembly
program. This assignment implements a binary translator
for a subset of RISC-V instructions. This subset is Turing-complete, and thus anything could
theoretically be computed with this subset. Additionally, special consideration must be given
to branch instructions, the encoding of immediates in I-type or shift RISC-V instructions,
and using the zero register.
The solution for this assignment must implement the following functions:
RISCVtoWASMa0: pointer to memory containing the binary representation of a
RISC-V function. The end of the RISC-V program is marked by the sentinel word
0xFFFFFFFF (The integer -1).
a1: pointer to pre-allocated memory where the generated WASM binary
representation of a function must be stored.
a0: The number of bytes of WASM code that were generated by the
function.
a1. The end of the binary representation
MUST BE the instruction (return (get_local 0))
followed by the end opcode.
translateITypea0: Address to write instruction representation translated into WASM.
a1: Address of the RISC-V instruction to parse.
a2: WASM opcode for the WASM instruction to build. NOT the
RISC-V opcode for the instruction.
a0: The number of bytes in the translated WASM instruction.
a0.
translateRTypea0: Address to write instruction representation translated into WASM.
a1: Address of the RISC-V instruction to parse.
a2: Opcode for the WASM instruction to build. NOT the RISC-V opcode
for the instruction.
a0: The number of bytes in the translated WASM instruction.
a0.
translateBrancha0: Address to write instruction representation translated into WASM.
a1: Address of the RISC-V instruction to parse.
a2: Opcode for the WASM instruction to build. NOT the RISC-V opcode
for the instruction.
a0: The number of bytes in the translated WASM instruction.
a0.
encodeLEB128a0: A 12-bit two-complement value, stored in the lower half of the
word, to be converted into LEB128 representation.
a0: The LEB128 representation of the input
value. The least-significant byte of the LEB128 representation
should be in the least-significant byte of
a0. Examples of conversions are shown here
a1: The number of bytes that were needed to represent the resulting
LEB128 formatted value.
generateTargetTableincrTargetCount as a helper function.a0: Pointer to the binary representation of the RISC-V program.
readTargetCounta0: Pointer to the binary representation of the RISC-V program.
a1: Instruction address to get the count for.
a2: Flag denoting whether the instruction is the target of a forward
or backward branch; 1 = forward, 0 = backward.
a0: The associated count of how many branches have the given
instruction as a target.
incrTargetCountgenerateTargetTable.a0: Pointer to the binary representation of the RISC-V program.
a1: Address of the instruction to increment the count for.
a2: Flag denoting whether the instruction is the target of a forward
or backward branch; 1 = forward, 0 = backward.
RISCVtoWASM. If you still find yourself
stuck/overwhelmed, reach out to a TA for help.
The functions provided in the spec are designed in such a way as to help guide you through solving
the overall task of the lab. Below is a diagram depicting the intended control flow of the program,
at a function level
(You of course can add your own functions and modify where you make function
calls as you see fit):
To generate test cases, write short structured RISC-V programs using the subset of instructions provided, and convert them into binary files using the following command:
rars "YOUR_RISCV_FILE" a dump .text Binary "YOUR_DESIRED_BINARY_FILE"
The provided common.s file loads RISC-V binary from
a file and generates a .wasm file after calling the functions specified above. The program
in common.s takes the name of the file containing the test to load as an
argument. Thus, it can be run using rars common.s pa RISCV_BINARY_FILE.
The submitted solution must not contain the common.s attached.
It also must not contain a main function.
You are given a browserWASM.html
file to run your WASM modules. This implementation uses a
WebAssembly Javascript API. The completion of this assignment does not
require that the module be run on a browser. However, doing so would allow you to check
that the implementation of the encodeLEB128 function is correct and
that the generated WASM preserves the semantics of the input RISC-V program.
This assignment also provides the program WASMDisassembler.s that prints WASM instructions in a WAST textual representation. The output of the disassembler is one instruction per line and all expressions are presented in postfix order. This disassembler prints only values that meet the above spec, producing question marks where no valid interpretation is possible. You are responsible for creating test cases to ensure compliance with the assignment specification. The program can be run using:
rars WASMDisassembler.s pa main.wasm
The program terminates on the WASM module return opcode. Therefore any
output should, at the very least, contain a return statement in order to run the
disassembler. The disassembler can be tested from the very start of this assignment
using the provided .wasm files in the
browserTool directory.
To view the bytecode contents of the generated .wasm files in a terminal,
use the following command:
hexdump main.wasm
Another tool that may prove useful for testing your submission is the wat2wasm tool, which takes the WAST representation of a program and converts it to the WASM byte code.
Here are some test cases that you can use to test your program.Class slides used for the lab (.pptx) (.pdf)
Class presentation for the lab (Google Drive) (YouTube)
Some test cases as well as tools to aid in test case generation are available in
the Code directory and instructions can be found in the
README.
You can use the online WebAssembly Studio to see the translation of C/Rust/WAST code to WASM/WAST.
More information on WebAssembly can be found here.
Assignments too short to be adequately judged for code quality will be given a zero. Register translation is vital for all instructions. Therefore it is difficult for a binary translator that does not do correct register translation to pass ANY of the grading test cases. Please, ensure proper register translation according to the table above.
A copy of the marksheet to be used can be found here. For the instruction translations, an incomplete set of translated instructions can still earn part marks.
Files to submit for this assignment:
wasm.s should contain the assembly program you wrote.main label to this file.include "common.s"wasm.s
